Tehnični podatki
Podatki o motorju
Moč motorja s1 (W)
3000
Moč motorja s6 (W)
4000
Napetost
400V / 3 / 50Hz
Dimenzije
Dimenzija mize (mm)
1000 x 350
table višina (mm)
890
Drsna miza (mm)
1000 x 310
Odsesovanje (mm)
100
Tehnične podrobnosti
milling spindle diameter (mm)
30
milling spindle hitrost (v minuti)
1400 / 3500 / 6000 / 8000
spindle stroke (mm)
130
max. milling diameter (mm)
175
milling spindle swivel
(-5)0-45°
max. clamping višina (mm)
140
table opening (mm)
178
max. tool diameter below table (mm)
170 (90°) , 100 (45°)
max. tool diameter above table
200
mitre fence (mm)
450 x 160 (L +R)
Glasnost
sound power level - dB(A)
96,8
sound pressure level - dB(A)
80,7
Teža
Bruto teža (v kg)
343.50
Neto teža (v kg)
280
Dimenzije pakiranja
Dimenzije pakiranja širina (mm)
900
Dimenzije pakiranja dolžina (mm)
1.150
Dimenzije pakiranja višina (mm)
1.078
Splošni podatki
EAN koda
9120058377150
